Speed-optimized desktop scanner with color texture capture. At ≤10 μm accuracy and 5-second bite scans, the Pro(C) is built for high-volume labs where throughput matters as much as precision.
See AutoScan-DS-EX Pro(C) in action
Why the Pro(C)
Color texture scanning — captures shade and surface detail in full color. Useful for shade matching, documenting stain effects, and communicating with clinicians.
No spray needed — scans reflective surfaces (die stone, metal abutments) without anti-reflective spray. Saves time and avoids coating artifacts.
5-second bite scan — fastest in its class. Full upper/lower jaw in 9.5 seconds. Impression scan in 22 seconds.
AI scan recognition — intelligent scan path reduces technician workload by 30%. The scanner determines optimal angles automatically.
Scan Times
Bite Registration
5 seconds
Upper/Lower Jaw
9.5 seconds
1-4 Dies
15 seconds
5-8 Dies
17 seconds
Full Impression
22 seconds
Specifications
Accuracy
≤10 μm (no targets needed)
Cameras
Dual 5 MP
Light Source
Blue light
Dimensions
420 × 260 × 270 mm
Weight
5.0 kg
Export
STL, PLY, OBJ
Applications
Wax-ups, abutments, dies, plaster models, impressions, articulators, and texture scans. Compatible with exocad, 3Shape, Dental Wings, and all major CAD/CAM platforms.
Computer requirements
DesktopScan/DentalScan workflows need a dedicated Windows workstation with NVIDIA graphics.
Operating system
Windows 10 1809 or Windows 11
CPU
Intel Core i7-8700 or above
Memory
32 GB or above for EX Pro impression scanning workflows
Graphics
NVIDIA GTX 1060 6 GB or above; NVIDIA Quadro is not compatible
Storage
At least 2 GB for software and 20 GB for order storage
Connection
One USB 3.0 port for the scanner and one USB port for the dongle
Power
AC input 100-240V, 1.5A, 50-60Hz
Estimated shipping time
2-3 weeks
Estimate for planning. Final timing is confirmed after order review.
